SmartCAM - smart traffic camera with onboard ANPR

SmartCAM – this cost-effective third generation ANPR camera combines high quality imaging with onboard plate recognition. The SmartCAM family includes a wide range of models: in some variants the dual sensor dual lens design serves to further enhance number plate recognition accuracy, in others it functions as an Overview camera.

The camera runs 4 pre-installed plate recognition engines by default, which covers most common license plates worldwide. SmartCAM recognizes plates very fast, partly because of parallel multi-core operation, partly due to an integrated vehicle detection algorithm that preselects the relevant images for the ANPR module. Perfect imaging is assisted by built-in smart illumination that also has a synchronized flash mode which guarantees the the recognition of reflective and non-reflective number plates at the same time. Precise location data is provided by the camera’s optional GPS, and https remote access is possible via the 4G/LTE add-on. At the end of the process the camera provides the requested data by exporting the events in the form selected by the user. In effect, it is a true stand-alone traffic solution. SmartCAM’s advanced technology is encased in a tough IK10 & IP67 industrial grade housing for enhanced protection.

SmartCAM offers:
  • 2+4 cores with on-board ANPR
  • Wide range of models: from the cost-efficient single lens version to our most powerful ANPR camera
  • Second camera module available as an Overview sensor or an Advanced Vision solution (glare-free and shadow-free imaging)
  • Optimal cooperation of hardware and software: the camera and the plate recognition engine were developed by the same manufacturer
  • Integrated smart illumination – it makes the recognition of reflective and non-reflective plates possible at the same time

SmartCAM provides solution for common problems by:
  • Guaranteeing fast operation due to a powerful processor and an image preselection algorithm
  • Transporting ANPR results directly to a specified database
  • Offering the option of an Overview lens to see the big picture or an Advanced vision lens for enhanced ANPR
  • Having a modular design for optional radar and illumination add-ons

SmartCAM is ideal for:
  • Applications where Automatic Number Plate Recognition inside the camera is an advantage
  • Cost-efficient solutions
  • Systems with low band-width capacity

SmartCAM combines ANPR/LPR camera, IR illumination, 4G modem and IP communication capability, GPS, data processing and (optional) Doppler speed radar in a single IP67 rated unit. The device automatically performs time synchronization (NTP) and image capturing in 30 FPS in any weather and light condition. Its built-in motion detection with extensive masking option, ONVIF compatibility, JPEG image / MJPEG stream output and internal buffer, synchronized IR (or optional white) LED illumination provide ideal image capturing and control.

The camera’s extensive ability for traffic counting, analysis and to directly control external devices, such as speed radars, illuminators, barriers as well as its accessibility through the web makes the perfect unit for a wide range of applications.

Production Code SmartCAM-03-6450 SmartCAM-03-6452 SmartCAM-03-6552 (850nm)
SmartCAM-03-655A (760nm)
Generation Third
Function of the second sensor Overview Advanced Vision
Resolution (primary + secondary) 752 × 480 1440 × 1080 + 1920 × 1080 2048 × 1536 + 1280 × 960
Typical frame rate (primary + secondary) 60 FPS 30 FPS + 30 FPS 30 FPS + 54 FPS
Optical zoom (primary camera) 11× 3.3×
Image Buffer / Event Storage (approx.) 800 / 40K 500 / 30K
Illumination wavelength 850 nm (infrared) 760 nm or 850 nm (infrared) 850 nm (infrared)
Optimal OCR range at ambient light 4 m ‒ 20 m (13 feet ‒ 65 feet) 10 m ‒ 20 m (33 feet ‒ 65 feet)
Built-in Vehicle Detection Included
Built-in RADAR Optional Radar
On-board computer (independent CPU cores) ARM 2×766 MHz + 4×1 GHz ARM 2×766 MHz + Intel Atom 4×1.9 GHz
Operating temperature range -45 °C ‒ 70 °C
IP & IK rating IP67 & IK10
Full remote access YES (HTTPs)
4G & GPS Optional
Optional accessories I/O Cables, FreewayCAM IR-Light3, FreewayCAM RAD-AR Trigger, Junction Box
